Ambulatory Monitoring Device Ecg Test For 12 Channel / 3 Channel Holter Monitor

Ambulatory ECG Monitoring For 12 Channel or 3 Channel Holter Monitor

The CV3000 Holter ECG is intended for patients requiring ambulatory (Holter) monitoring. The following is a listing of the most frequently used for the indications below:

(1) Evaluation of symptoms suggesting arrhythmia or myocardial ischemia.

(2) Evaluation of ECG documenting therapeutic interventions in individual patients or groups of patients.

(3) Evaluation of patients for ST segment changes

(4) Evaluation of a patient’s response after resuming occupational or recreational activities.

(5) Evaluation of patients with pacemakers.

(6) Reporting of time and frequency domain heart rate variability.

(7) Reporting of QT Interval.

Specifications

Channels: 12leads (8 channel) 5leads(3 channel)
Resolution: 8-16 bits

Recording: Full disclosure

Download interface: SD card reader or USB line

Sample rate:1024/Sec max

Frequency response: 0.05HZ to 60Hz

Signal verification: LCD display

Pacemaker Detection: support

Memory

Recording time: 24-72 hours

Type: SD

Capacity: 2GB

Physical

Dimensions: 72*53*16mm

Weight with battery: 62g

Enclosure: ABS plastic

Operating position: any orientation

Electrical

Gain settings: 0.5X, 1X and 2X

Connector: 19 pin

Patient cable: 10 leads or 5 leads
