High Light: | ECG monitoring device,ECG Workstation |
---|
Heart Rate Monitor ECG Monitoring Device 12 channel iPad ECG Machine
Quick Detail
Name |
Profession and fashion rest ECG |
Function |
Automatical monitor and analysis ECG |
Type |
Resting |
Feature |
Wifi connection |
Leads |
Simultaneous 12 leads |
certification |
CE ISO |
Description
Brand Name |
V&H |
Model Number |
ICV200 |
Place of Origin |
Beijing, China (Mainland) |
Color |
white |
Transfer way |
wireless |
Properties |
Diagnostic Instruments |
Other |
icloud ECG web |
Advantages:
Vales and Hills Biomedical Tech. Ltd. (V&H), located on BDA International Park, BEIJING, has been one of the leading developers of PC based ECG technology for years. V&H keeps giving great resources to approach the edge that comes with the idea of sophisticated simplicity in products design and the discipline of management in quality control. V&H is mostly engaged in PC-ECG, ECG Workstation, ECG Stress Test, Digital EEG Series and Ambulatory Blood Pressure Monitor. V&H's core concept is teamwork on which we have built a truly top-notch team, conceived in collaboration, dedicated to the proposition that we all colleagues working our hearts out toward the goal in rewarding people and society. V&H keeps looking to the future with hope and determination.
ECG Recorder Specifications
Sampling Rate |
A/D:24K SPS/Ch Recording:1K SPS/Ch |
Quantization Precision |
A/D:24 Bits Recording:16 Bits |
Resolution |
0.4uV |
Common Mode Rejection |
>110dB |
Input Impedance |
>20M |
Frequency Response |
0.05-250Hz(±3bB) |
Time Constant |
>3.2Sec |
Maximum Electrode Potential |
±300mV DC |
Dynamic Range |
±15mV |
Defibrillation Project |
Build-in |
Communication |
WIFI(ipad,iphone)Blue Tooth(Android) |
Power |
2xAA Batteries |
