Stress Test Home ECG Machine 12 Channel Home Exercise Ecg Machine USB Cable

large.img.alt
small.img.alt small.img.alt small.img.alt

Large Image :  Stress Test Home ECG Machine 12 Channel Home Exercise Ecg Machine USB Cable Get Best Price

Product Details:
Place of Origin: Beijing,China(Mainland)
Brand Name: V & H
Certification: CE&ISO
Model Number: CV-1200
Payment & Shipping Terms:
Minimum Order Quantity: 1 Unit
Packaging Details: Standard Package:25cm*20cm*13cm
Delivery Time: 5-8 Work days
Payment Terms: Western Union, T/T, L/C
Supply Ability: 50 Units Per Week
Detailed Product Description
Product: Top Quality 12 Channel Home Exercise Ecg Machine From China Supplier Type: Stress Test
Cable: Simultaneous 12-lead Data Transmission: USB Cable
Defibrillation Protect: Build-in Input Impedance: >20MΩ
Frequency Response: 0.05-250HZ Communication: USB
Time Constant: 3.2Sec
High Light:

12 lead ecg machine

,

small ecg machine



Top quality 12 channel home exercise ecg machine from China supplier





Reflecting the latest development in stress system



V&H newly developed CV1200 is a high-performance cardiac stress system which incorporates the latest innovations with the easy of use workflow and intuitive icons and controls that you come to expect in CardioView series. Thanks to its elaborately designed ECG acquisition device and proprietary digital processing algorithms, CV1200 is specially featured in its super-stable and noise-free ECG tracings even at steep grades. The sophisticated software gives you a perfect solution for cardiology diagnosis as well as a fantastic user experience.





Why select CV1200——Advantages:



  • High resolution A/D: 24K SPS/Ch, 24 bits
  • VH patent technology: Digital synchronous A/D
  • VH patent technology: Myoelectric filter based on ECG spectrum
  • VH proprietary algorithm: Minimum delay baseline wander eraser
  • Different filters selectable : LP, HP and artifact filters
  • Skin-electrode impedance measurement
  • Preset classical protocols and unlimited user defined protocols
  • Arrhythmia detect and live review
  • Various trends: tracking and compare
  • Soft anti-aliased ECG display
  • ECG, BP, SO2, METS, max VO2, Distance and Time synchronous display
  • Rehabilitation mode: Cardiac function recovery protocols
  • Independent testing for different treadmills and ergometers



Specification



CV-1200 Specification

System







Monitor 17" colour,high resolution
Operator interface Standard alphanumeric PC keyboard, and mouse
Power requirement 110/230V,50/60Hz
Battery emergency ECG capability with uninterrupted internal power supply for up to 3 minutes
Operating system Microsoft Windows XP, Ergometer, Treadmill, NIBP
Printing Chart paper Thermo reactive, Z-fold,width,A4
Paper speed 12.5/25/50mm/sec
Sensitivity 5/10/20mm/mV
Print format 6/12 channel printout,
Automatic baseline adjustment
Technical Date Frequency Response



0.05-70Hz(+3dB)

Sampling rate 1000Hz/ch
CMR >90dB
Maximum Electrode Potential +300mV DC
Isolation 4000V
Current Leek <10µA
Digital Resolution 12 bits
Input range +10 mV
Software optional Automatic ECG measurements and interpretation,
Vector Cardiograph
Ventricular Late Potentials, QT Dispersion
Environment Condition Temperature operating 10 to 40
Temperature storage -10 to 50
Pressure operating 860hPa to 1060hPa
Stress Test Home ECG Machine 12 Channel Home Exercise Ecg Machine USB Cable
Our service:

1. Warranty —— offer 12 months free after-sale services for customers, and be responsible for life-time repair.
2. Technical —— Offer professional engineers for customers on the technical support.
3. Freight —— Pay  for freight when we ship the repair product.
