16 Bits Portable Smart IPad ECG Machine / IPod Rest ECG Machine For Medical

I'm Online Chat Now
Certification
Good quality Handheld ECG Machine for sales
Good quality Handheld ECG Machine for sales
Good quality and good service

—— Dr.Alam from Egypt

Perfect product,small and smart!

—— Mr.Yann from France

16 Bits Portable Smart IPad ECG Machine / IPod Rest ECG Machine For Medical

large.img.alt
small.img.alt small.img.alt small.img.alt

Large Image :  16 Bits Portable Smart IPad ECG Machine / IPod Rest ECG Machine For Medical Get Best Price

Product Details:
Place of Origin: China(Mainland)
Brand Name: V&H
Certification: CE & ISO
Model Number: iCV200BLE
Payment & Shipping Terms:
Minimum Order Quantity: 1 set/sets
Packaging Details: standard package
Delivery Time: 7 work days
Payment Terms: T/T, L/C, Western Union
Supply Ability: 50 sets per week
Detailed Product Description
Product: New Design Portable Smart IPad / IPod Rest ECG Machine For Medical Type: Resting
Transfer Way: Bluetooth Recording: 16 Bits
Power: 2*AA Batteries Color: White
High Light:

bluetooth ecg device

,

iphone ecg monitor



New design portable smart iPad / iPod rest ECG machine for medical



Advantages:

  1. The first professional elsctrocardiogram (ECG) product developed on android portable device.
  2. High-definition ECG display thanks to its Apple high resolution screen and anti-aliased algorithm.
  3. Automatic measurements and interpretations.
  4. Bluetooth communication



ECG Recorder Specifications



Sampling Rate

A/D:24K SPS/Ch

Recording:1K SPS/Ch

Quantization Precision

A/D:24 Bits

Recording:16 Bits

Common Mode Rejection >110dB
Resolution 0.4uV
Input Impedance >20M
Frequency Response 0.05-250Hz(±3bB)
Time Constant >3.2Sec
Maximum Electrode Potential ±300mV DC
Dynamic Range ±15mV
Power 2xAA Batteries
Communication WIFI(ipad,iphone)Blue Tooth(Android)
Defibrillation Project  Build-in





16 Bits Portable Smart IPad ECG Machine / IPod Rest ECG Machine For Medical
