Portable Handheld PC ECG Machine , 12-channel pc ecg device with cheap price

large.img.alt
small.img.alt small.img.alt small.img.alt small.img.alt small.img.alt

Large Image :  Portable Handheld PC ECG Machine , 12-channel pc ecg device with cheap price Get Best Price

Product Details:
Place of Origin: China
Brand Name: V&H
Certification: CE,ISO13485,FREE SALES
Model Number: CV200
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Packaging Details: Standard Package
Payment Terms: T/T, Western Union,Paypal
Supply Ability: 5 sets per day
Detailed Product Description
Product: Handheld PC ECG Monitor With Pan Shape Acquisition Box CV200 Color: Grey
Connection: USB/Wireless Function: ECG WORK STATION,Vector ECG
Channels: 12-LEAD ECG Sampling:: 1000 S/S/Ch,12 Bits, Simultaneously 12 Leads Recording
Patient Cable: Standard 10-wire,15-Pin D Connector Dimensions: 14912226 Mm(5.94.81.0 In.)
High Light:

ecg monitoring device

,

pocket ecg machine

Portable Handheld PC ECG Machine , 12-channel pc ecg device with cheap price





CV-200-Rest ECG,VCG and VLP

CARDIO VIEW CV-200 is a PC-ECG system for doctors and clinics with plans to make multi-function electrocardiograph analysis, including 12-lead Resting ECG, Vector ECG (VCG) and Ventricular Late Potential (VLP).The system automatically stores, analyzes, averages, displays and prints the recorded ECG,VCG and VLP data. In the Windows XP environment, different reports can be viewed on-screen and printed in numerous formats on most Windows compatible printers. By means of regular updating of software,CV-200 remains state-of-the-art both now and in the future. With the optical isolating ECG signal sampling recorder connected to PC USB interface,CV-200 guarantees high quality ECG data acquisition, user-friendly environment and 100% safety for the patient.

Minimum Computer System Requirements:

· Pentium III Processor

· 128MB RAM

· 20G HD

· Windows XP Operating System

· VGA Compatible Display

· Windows XP Compatible Laser or Inkjet Printer





               VH- CV200-ECG work station specification

Sampling

1000 S/S/Ch,12 bits, Simultaneously 12 Leads Recording

Digital Resolution

2µV

Frequency Response

0.05-250Hz(+3dB)

Common Mode Rejection

>90dB

Input Impedance

>10 M

Time Constant

3.2 Sec

Maximum Electrode Potential

+300mV DC

Dynamic Range

+10mV

Isolate Voltage

4000V

Current Leek

<10µA

Patient Cable

Standard 10-wire,15-Pin D Connector

PC Interface

USB Connector

Dimensions

14912226 mm(5.94.81.0 in.)





Portable Handheld PC ECG Machine ,  12-channel pc ecg device with cheap price







Portable Handheld PC ECG Machine ,  12-channel pc ecg device with cheap price

Portable Handheld PC ECG Machine ,  12-channel pc ecg device with cheap price
