Treadmill Stress Test ECG Machine CV1200 With High Quality Options Ergometer

small.img.alt small.img.alt small.img.alt small.img.alt

Large Image :  Treadmill Stress Test ECG Machine CV1200 With High Quality Options Ergometer Get Best Price

Product Details:
Place of Origin: China
Brand Name: V&H
Certification: CE,ISO13485,FREE SALES
Model Number: CV1200
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Packaging Details: package/carton
Delivery Time: Within 1 week after receiving payment
Payment Terms: T/T,, Western Union,PAYPAL
Detailed Product Description
Type: Biochemical Analysis System Color: Grey And White
Cable: Simultaneous 12-cahnnel Function: Automatic Measurement And Interpretation
Measurement Full Disclosure: Exercise ECG With ST And Rhythm Measurements Gurantee: 1 Year
High Light:

ecg monitoring device


pocket ecg machine

Treadmill Stress Test ECG Machine CV1200 With  High Quality Options Ergometer
As a multi-function ECG Workstation, the iCV1200 ECG Acquisition Systems increase the stress test function, it will give you a totally new feeling, which will help you work swiftly, diagnose accurately and get to a new high level of your career. The ECG Acquisition Systems can work smoothly interfacing with treadmill and ergometer.
n   12 lead ST segment measurement point can be set and changed according to HR by user during data sampling
n   Real time analyze HR,ST segment and their trends, real time display and print 12 leads simultaneous ECG
n   Protocols can be edited flexibly to work with different manufacturers’ treadmills
n   Recorded ECG data can be replayed, so it is very convenient for doctors to view the ECG changes
n   Offer detailed data for all stages
n   Offer average ECG waves for 12 leads and all stages, help doctor to see the changes among different stages
n   Treadmill starts from zero speed to ensure safety of patient
n   Auto control of the speed and incline of the treadmill
n   Test heart rate dynamically and Give alarm signal automatically
n   Can save large quantity of patient data which can be reviewed, frozen and analyzed by doctors at any time
n   Unique anti-artifact protocols to ensure stable waves
n   Real time print of many selectable formats, no special printing paper needed
n   Capacity for processing and memorizing numerous data

2.2 Device specification

Sampling: 1000Hz
Channels: 12
Sensitivity; 5/10/20mm/mV
Frequency Response: 0.05-250Hz(±3dB)
Common Mode Rejection: >60dB
Input Impedance: >5MΩ
Isolate Voltage: 4000V
Polarity voltage: ±300mV
Current leak :< 20μA
PC Interface: USB Connector
Dimensions: 15L×8W×2.5H cm

                      CV-1200 Specification



17"colour,high resolution

Operator interface

Standard alphanumeric PC keyboard, and mouse

Power requirement



emergency ECG capability with uninterrupted internal power supply for up to 3 minutes

Operating system

Microsoft Windows XP, Ergometer, Treadmill, NIBP


Chart paper

Thermo reactive, Z-fold,width,A4

Paper speed




Print format

6/12 channel printout,
Automatic baseline adjustment

Technical Date

Frequency Response


Sampling rate




Maximum Electrode Potential

+300mV DC



Current Leek


Digital Resolution

12 bits

Input range

+10 mV

Software optional

Automatic ECG measurements and interpretation,
Vector Cardiograph
Ventricular Late Potentials, QT Dispersion

Environment Condition

Temperature operating

10 to 40

Temperature storage

-10 to 50

Pressure operating

860hPa to 1060hPa
