Product Details:
Payment & Shipping Terms:
|
Product: | 2017 Latest 12 Channel Low Power Bluetooth Ecg Machine For Clinic | Type: | Resting |
---|---|---|---|
Transfer Way: | Bluetooth | Defibrillation Protect: | Build-in |
Channel: | Standard 12 Channel | Dynamic Range: | ±15mV |
Power: | 2 AA Batteries | Sampling Rate:: | A/D: 24K SPS/Ch; Recording: 1K SPS/Ch |
High Light: | wireless ecg machine,cardiac monitoring equipment |
2017 latest 12 channel low power bluetooth ecg machine for clinic
Advantages:
For analysis APP, Most of the ECG related Apps on App Store are for education or practice
iCV200BLE is for real heart disease diagnosis, and target for hospitals, healthcare organizations or Cardiology doctors
ECG Recorder Specifications
Sampling Rate |
A/D:24K SPS/Ch Recording:1K SPS/Ch |
Quantization Precision |
A/D:24 Bits Recording:16 Bits |
Common Mode Rejection | >110dB |
Resolution | 0.4uV |
Input Impedance | >20M |
Frequency Response | 0.05-250Hz(±3bB) |
Time Constant | >3.2Sec |
Maximum Electrode Potential | ±300mV DC |
Dynamic Range | ±15mV |
Power | 2xAA Batteries |
Communication | Bluetooth |
Defibrillation Project | Build-in |
About Us
Vales and Hills Biomedical Tech.Ltd is a global provider centralizing of electrocardiograph(ECG) products and ECG web services for clinical applications. For over 10 years,we have been creating a complete CardioView product line which covers Portable ECG(IOS and Android ), PC-ECG,ECG Workstation,Holter,ABPM, ECG Network and ECG Cloud Service.
Which a pioneering spirit in technology innovation, V&H has set up a truly top-notch team with determination, conceived in collaboration, dedicated to the proposition that clients and people are the first to be focused on. We continue to invest in advanced technology to meet the ever-changing clinical needs of the market.
