Stress Tesing Portable Multi Channel Ecg Machine CV1200 USB Cable Connection
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Color: | Grey | Type: | Stress Tesing |
|---|---|---|---|
| Channel: | 12-channel Ecg Detection | Connective Way: | USB Cable |
| Defibrallation Protection: | Supported | Operation Systems Supported: | Win Xp,7,8,10 |
| High Light: | wireless ecg machine,cardiac monitoring equipment |
||
Stress Tesing Portable Multi Channel Ecg Machine CV1200 USB Cable Connection
CV-1200 Stress Test System is a perfect solution for Cardiology Diagnosis, it provides Record, Display, Archived, and Analyze ECG Recording and other Measurements
Standard Features
-
Automatic ECG measurements and interpretation
-
12- channel fulldisclosure exercise ECG,with ST measurement and rhythm measurement
-
Real time display,analyze HR,ST segment,and reanalyze ST segment
-
ST,Delta ST,ST/HR,ST slope,J point and R point trends
-
Data management system
-
Built-in thermal printer records,3,6,or 12 channels simultaneously in real time
-
Common laser printer interface for documentation on standard(A4) paper
-
CV-1200 controls selection of peripheral
equipment(ergometers,treadmills and NIBP) through integrated interface protocols(Bruce,Bruce modified,Balke ware,Ellestad,ect.) -
Large color screen with high resolution for paperless operation
-
Micosoft Windows XP operating system
Specification
CV-1200 Specification |
||
System |
Monitor |
17" colour,high resolution |
Operator interface |
Standard alphanumeric PC keyboard, and mouse |
|
Power requirement |
110/230V,50/60Hz |
|
Battery |
emergency ECG capability with uninterrupted internal power supply for up to 3 minutes |
|
Operating system |
Microsoft Windows XP, Ergometer, Treadmill, NIBP |
|
Printing |
Chart paper |
Thermo reactive, Z-fold,width,A4 |
Paper speed |
12.5/25/50mm/sec |
|
Sensitivity |
5/10/20mm/mV |
|
Print format |
6/12 channel printout,
|
|
Technical Date |
Frequency Response |
0.05-70Hz(+3dB) |
Sampling rate |
1000Hz/ch |
|
CMR |
>90dB |
|
Maximum Electrode Potential |
+300mV DC |
|
Isolation |
4000V |
|
Current Leek |
<10µA |
|
Digital Resolution |
12 bits |
|
Input range |
+10 mV |
|
Software optional |
Automatic ECG measurements and interpretation,
|
|
Environment Condition |
Temperature operating |
10 to 40 |
Temperature storage |
-10 to 50 |
|
Pressure operating |
860hPa to 1060hPa |
|
